Chapter 2 - RIRA

The RIRA is all about the “touchy, feely” side of cycling. Whilst the svelte weight and the carefully dialled stiffness to weight ratio matters to our product team who geek out over Toray T1100 grade specifications, fibre orientation and watts saved etc., it’s what we deliver to your soul that matters to us most.

With the RIRA, we got back to basics. A razor-sharp focus on balance and agility that is sure to raise your pulse, and if that wasn’t enough, it has the looks that will certainly turn a few heads when you rock up to your local bunchie or put the power down to capture your PB.

The RIRA sports a T47 85.5 BB Standard that is quickly becoming the default standard for high tolerance and stiffness, as well as offering many BB and Crankset options in the market. By using a standard 27.2mm Seatpost, you can really dial in your bike fit as well as target weight. Of course, you can also choose the optional C2 TUMU Seatpost at 219g to get the full C2 experience.

The RIRA frameset comes with Sram UDH Hanger and Shimano Direct Mount Hnager and is only compatible Electronic Groupsets. The chassis and fork accommodate tires up to 32mm in the rear and 34mm in the front, ensuring a smooth and fast ride, so you will have ample room for high volume tires for the fast and plush ride quality.

See more details at Chapter2!

FRAME GEOMETRY

Note:

All dimensions are in mm unless otherwise noted

RIRA	XS	S	M	L	XL
Stack	489	517	545	573	601
Reach	361	371	381	391	401
A. Top Tube	502	520	538	555	574
B. Head Tube	90	112	135	161	191
C. Seat Tube Angle	74°	74°	74°	74°	74°
D. Head Tube Angle	70°	72°	73°	74°	74°
E. Seat Tube	430	450	470	500	530
F. BB Drop	74	73.5	73	72.5	72
G. Rear Centre	410	410	410	410	410
H. Wheelbase	972	974	975	982	1001
I. Front Centre	574	576	574	584	602
J. Fork Offset	53	53	43	43	43
K. Seatpost Setback	NA	NA	NA	NA	NA
Stem	NA	NA	NA	NA	NA
Stand over	721	744	768	799	827
Rider Height	<170	165-175	170-180	175-185	>180
Max. Tire Size	32	32	32	32	32
Rear Caliper Mount	25	25	25	25	25
Note: All dimensions are in mm unless otherwise noted.
